BlueSolar PWM-Pro Charge Controller 12/24 V-5 A Victron Energy
Manufacturer:
INDEX: SCC010005010
BlueSolar PWM is a charging regulator for cooperation in PV systems and is used in systems with energy banks. After connecting to the system, it is immediately ready to work in the default settings.
Distinguishing features of the product:
Lighting control function, fully programmable
Three stage battery charging (bulk, absorption, float), fully programmable
Integrated battery monitor function (Remote Panel needed to display state of charge)
Load output with low voltage disconnect and manual control (default setting)
Load output protected against over load and short circuit
Optional external temperature sensor
Protected against reverse polarity connection of the solar array and/or battery
| Maximum PV voltage [V]: | 28 |
|---|---|
| Nominal battery voltage [V]: | 12 / 24 |
| Charge voltage, float [V]: | 13.8 / 27.6 |
| Charge voltage, absorption [V]: | 14.4 / 28.8 |
| Charge voltage, equalization [V]: | 14.6 / 29.2 |
| Low voltage load disconnect [V]: | 11.1 / 22.2 |
| Low voltage load reconnect [V]: | 12.6 / 25.2 |
| Rated charge current [A]: | 5 |
| Self-consumption [mA]: | 10 |
| Dimensions WxHxD [mm]: | 138 x 70 x 37 |
|---|
